Komax Mira 340
'As new' condition machine, offered with installation, commissioning and training - as required
Also, we are offering a full 1 year warranty with this machine.
Regret UK sales only.

Specifications
Wire outer diameter max.    8 mm
Strip lengths, full stripping max.    72 mm
Insertion depth with standard grippers min.    12 mm
Number of entries in the article library    3000
Number of entries in sequence library    1000
Strip lengths, full stripping min.    0.01 mm
Strip lengths, partial stripping min.    0.01 mm
Strip lengths, partial stripping max.    32 mm
Increment of strip length    0.01 mm
Cutting length for wire tip min.    0.01 mm
Cutting length for wire tip max.    72 mm
Max. conductor diameter for cutting    2 mm
Blade    4x
Incision diameter increment    0.01 mm
Wire cross section min.    0.013 mm²
Wire cross section max.    16 mm²
Gripping force    Programmable
Sequence function/number of steps    100
Noise level    < 80 dB
Electrical connection    100–240 V AC, 120 VA
Compressed-air connection    6 – 8 bar
Compressed-air quality    Dry, filtered (10 μm), oil-free
Weight    11 kg
Dimensions/length    141 mm
Dimensions/width    473 mm
Dimensions/height    290 mm
Temperature operation    5 – 40 °C
Processing outside the specifications    Processing outside the specifications upon request. In case of doubt, we will be happy to provide processing samples for your wires.
Cycle time    2.3 sec
Data interface    USB interface for data backup, input for barcode scanner. Ready for connection to TCP/IP network connection
Input for barcode scanner    Data input mode: Configure scanner for “Keyboard wedge” or “USB keyboard wedge”. No driver needs to be installed. The readable code types depend on the barcode scanner model.
User interface    5-color touchscreen, dial wheel
Trigger    Sensor, touchscreen, foot-operated switch (optional)
